Inconel 825 Ball Valve

Home > Inconel >Inconel 825 Ball Valve

Jassem Tube Fittings is a reliable manufacturer and supplier in Doha, Qatar, offering high-quality Inconel 825 Ball Valves designed for smooth flow control and dependable shut-off in highly corrosive environments. These valves are engineered to perform consistently under high pressure and elevated temperatures while maintaining tight sealing and easy operation. Manufactured with precision machining and strict quality standards, Jassem Tube Fittings ensures long service life and operational safety. Inconel 825 is widely valued for its excellent resistance to corrosion, making these ball valves an ideal solution for critical industrial applications.

Inconel Instrumentation 825 Ball Valve Manufacturer in Doha, DIN 2.4858 Inconel Alloy Compression 825 Ball Valve in Al Khor, Inconel Hydraulic 825 Ball Valve Supplier in Al Rayyan, Inconel High Pressure 825 Ball Valve Price List in Doha, Inconel 2 Way 825 Ball Valve Price in Al Khor, Inconel Alloy 3 Way 825 Ball Valve in Doha, Qatar, Inconel 4 Way 825 Ball Valve Price in Al Wakrah, Inconel 5 Way 825 Ball UNS N08825 Valve Supplier in Al Rayyan, Inconel High Pressure 825 Ball Valve Price List in Al Shahaniya

Inconel 825 Ball Valves are made from a nickel-iron-chromium alloy with additions of molybdenum, copper, and titanium. This composition provides excellent resistance to general corrosion, pitting, and stress corrosion cracking. Mechanically, Inconel 825 offers good tensile and yield strength, high toughness, and stability across a wide temperature range. The alloy maintains its mechanical integrity under pressure, vibration, and thermal stress, ensuring smooth valve operation, reliable sealing, and long-term durability in aggressive service conditions.

Inconel 825 Ball Valve Specifications

SPECIFICATION	ASTM A494 / ASME SA494 API 602, ASME B16.34, SME B16.5, ASME B16.25, ASME B1.20.1, ASME B16.11, ASME B16.10, BS 5352, DIN3352
VALVE SIZE	1/8″ TO 2″ / 6 MM TO 50 MM
THREAD	NPT, BSPP, BSPT, JIC, METRIC, UNF
CONNECTION	THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE
FUNCTION	2 WAY, 3 WAY, 4 WAY, 5 WAY,
PRESSURE RATING	1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI
SEAL RING MATERIAL	PTFE, PVDF, DELRIN, PEEK, GRAPHITE
STANDARD	ISO, DIN , ANSI, API , ASME, AWWA , MSS,
MEDIA	HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER, COLD WATER, SEA WATER, CHEMICAL
MEDIA TEMPERATURE	(-120* C TO 500*C )RANGE AS PER PRESSURE
BODY TYPE	BAR STOCK
PACKING DETAILS	BOX PACKING, WOODEN PALLET
APPLICATION	MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERY, POWER GENERATING PLANT, STEEL MANUFACTURING PLANT, MINING INDUSTRIES, CHEMICAL PROCESSING MACHINES, PIPING LINE, PAINT INDUSTRIES, TRUCKS AND TRAILERS, AUTOMATION, AGRICULTURE MACHINES, AEROSPACE & DEFENCE EQUIPMENT,

Inconel 825 Ball Valve Chemical Composition

Grade	C	Mn	Si	S	Cu	Fe	Ni	Cr	Al	Ti
825	0.05 max	1.00 max	0.5 max	0.03 max	1.50 – 3.00	22.00 min	38.00 – 46.00	19.50 – 23.50	0.02 max	0.06 – 1.20

Inconel 825 Ball Valve Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
825	8.14 g/cm3	1400 °C (2550 °F)	Psi – 80,000 , MPa – 550	Psi – 32,000 , MPa – 220	30 %

Inconel 825 Ball Valve Equivalent

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN	OR
Inconel 825	2.4858	N08825	NCF 825	NA 16	ЭП703	NFE30C20DUM	NiCr21Mo	XH38BT

Top Inconel 825 Ball Valve Manufacturing Company in Doha

At Jassem Tube Fittings, we are the largest supplier, manufacturer, and exporter of Inconel 825 Ball Valve in Doha, Qatar. Our advanced manufacturing facilities, strategically positioned in the Qatar, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Inconel 825 Ball Valve

Inconel 3 Way 825 Ball Valve in Doha, Qatar, DIN 2.4858 Inconel Alloy 3 Way 825 Ball Valve Price List in Doha, Inconel 5 Way 825 Ball Valve Price in Al Khor, Inconel Instrumentation 825 Ball Valve Price in Al Wakrah, Inconel Compression 825 Ball Valve Supplier in Al Rayyan, Inconel Hydraulic 825 Ball Valve Manufacturer in Doha, Inconel Alloy High Pressure 825 Ball Valve in Al Khor, UNS N08825 Inconel 2 Way 825 Ball Valve Supplier in Al Rayyan

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Inconel 625 Ball Valve in Doha, Qatar

Jassem Tube Fittings is a leading supplier and stockist of premium Inconel 825 Ball Valve in Doha, Qatar. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Inconel 825 Ball Valve Uses

Inconel 825 Ball Valves supplied by Jassem Tube Fittings are widely used in chemical processing, oil and gas, petrochemical, and marine industries. They are ideal for handling acids, alkalis, seawater, and sour gas applications where corrosion resistance is critical. These valves are commonly installed in refineries, offshore platforms, pipelines, and process systems requiring reliable on-off control. Their durability, corrosion resistance, and ease of operation make them suitable for demanding environments where safety, efficiency, and long-term performance are essential.
