Jassem Tube Fittings has made a name for itself as a trusted manufacturer and supplier based in Doha, Qatar, providing top-notch valves and piping components for essential industrial systems. They specialize in Cupro Nickel Ball Valves, designed for reliable shut-off and smooth flow control, especially in corrosive and marine settings. Built to meet international standards, these valves are celebrated for their durability, leak-proof performance, and efficiency. Jassem Tube Fittings caters to the marine, offshore, oil & gas, and desalination sectors by offering Cupro Nickel Ball Valves that promise a long service life and dependable performance, even in tough operating conditions.
Cupro Nickel Ball Valves are crafted from copper-nickel alloys, typically in 90/10 or 70/30 ratios, with carefully controlled amounts of iron and manganese to enhance strength and resistance to corrosion. This alloy excels in resisting seawater corrosion, erosion, and biofouling. On the mechanical side, it boasts impressive tensile strength, ductility, and toughness, ensuring stable performance under moderate to high pressure and temperature. The material guarantees smooth ball rotation, effective sealing, and long-lasting dimensional stability.
| STANDARD | API 600/BS1414, API 598/BS EN 12266-1, ASME B 16.10, ASME B 16.5, ASME B 16.25, ASME B 16.34 |
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
| FUNCTION | 2 WAY, 3 WAY, 4 WAY, 5 WAY, |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
| SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
| STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
| MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
| MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK |
| BRAND NAME | TU-LOK |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| EQUIVALENT BRANDS | SWAGELOK, PARKER, DK-LOK, HAMLET, OLIVER VALVES, HOKE |
| APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cu Ni 90/10 | 88.6 min | 1.0 max | 0.05 max | 9-11 max | 1.8 max | 1 max |
| Cu Ni 70/30 | 65 min | 1.0 max | 0.05 max | 29-33 max | 0.4-1.0 max | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
At Jassem Tube Fittings, we are a leading supplier, manufacturer, and exporter of Cupro Nickel Ball Valve in Doha, Qatar. Our state-of-the-art manufacturing facilities, strategically located in the Qatar, enable us to deliver high-quality solutions that meet your specific requirements. With a comprehensive inventory of Monel materials, we are well-equipped to fulfill your needs efficiently. Our commitment to excellence and customer satisfaction ensures that we consistently maintain a ready stock of Monel Manifold Valves to support your operational demands.
| STANDARD | UNS | WERKSTOFF NR. |
| Cu Ni 70/30 | C71500 | 2.0882 |
| Cu Ni 90/10 | C70600 | 2.0872 |
Jassem Tube Fittings is a leading supplier and stockist of premium Cupro Nickel Ball Valve in Doha, Qatar. Our products find extensive application across diverse industries, and we are dedicated to delivering outstanding service while ensuring high customer satisfaction. Our specialized finishing techniques distinguish us in the metal industry, enhancing the performance and durability of our valves. We are committed to consistently providing top-quality Monel Manifold Valves while effectively addressing the unique needs of our customers.
Contact us to get a quick quote for your requirement.
Cupro Nickel Ball Valves find extensive use in marine and offshore piping systems where corrosion resistance is crucial. Common applications include seawater intake lines, shipbuilding, heat exchangers, condensers, and desalination facilities. They’re also utilized in oil & gas operations, power generation plants, and coastal industrial sites. These valves offer quick shut-off, minimal pressure drop, and low maintenance needs. Their robust nature and ability to withstand harsh environments make them perfect for long-term use in Qatar’s coastal and humid conditions.
Please feel free to contact us if you need any further information or for enquiry.
