Jassem Tube Fittings has earned a solid reputation as a reliable manufacturer and supplier based in Doha, Qatar, specializing in precision-engineered tube fittings for industrial fluid and gas systems. Their Bulkhead Union Elbows are expertly designed to facilitate smooth directional changes when passing through panels, tanks, or enclosures. Crafted to meet international standards, these fittings guarantee secure, leak-free connections and straightforward installation. Jassem Tube Fittings caters to various sectors, including oil & gas, chemical processing, instrumentation, and industrial automation, delivering Bulkhead Union Elbows that excel in durability, accuracy, and dependable performance even in challenging operating conditions.
Bulkhead Union Elbows are crafted from top-notch materials like stainless steel, carbon steel, brass, or specialized alloys, tailored to meet specific service needs. This careful selection of materials ensures they possess strength, corrosion resistance, and compatibility with a range of fluids and gases. On the mechanical side, these fittings boast impressive tensile strength, resistance to vibration, and stability under pressure. Thanks to precision machining, they feature smooth internal bores, accurate threads or ferrules, and reliable sealing performance across a wide spectrum of temperatures and pressures.
| Mcneil part no. | Equivalent Part no. Type 1 | Equivalent part no Type 2 | ODT-ØT(INCHES) | C | BODY HEX F | ODT-ØT1(INCHES) | Ø E | D | L | NUT HEX W | L1 |
| 1-BUD | -100-61 | 1BC1 | 1/16 | 0.43 | 5/16 | 1/16 | 0.05 | 0.34 | 0.84 | 5/16 | 1.24 |
| 2-BUD | -200-61 | 2BC2 | 1/8 | 0.60 | 7/16 | 1/8 | 0.09 | 0.50 | 1.50 | 7/16 | 2.02 |
| 3-BUD | -300-61 | 3BC3 | 3/16 | 0.63 | 9/16 | 3/16 | 0.12 | 0.54 | 1.59 | 7/16 | 2.11 |
| 4-BUD | -400-61 | 4BC4 | 1/4 | 0.70 | 5/8 | 1/4 | 0.19 | 0.60 | 1.03 | 9/16 | 2.27 |
| 5-BUD | -500-61 | 5BC5 | 5/16 | 0.73 | 11/16 | 5/16 | 0.25 | 0.64 | 1.81 | 5/8 | 2.39 |
| 6-BUD | -600-61 | 6BC6 | 3/8 | 0.76 | 3/4 | 3/8 | 0.28 | 0.66 | 1.87 | 11/16 | 2.45 |
| 8-BUD | -810-61 | 8BC8 | 1/2 | 0.86 | 7/8 | 1/2 | 0.41 | 0.90 | 2 | 7/8 | 2.80 |
| 10-BUD | -1010-61 | 10BC10 | 5/8 | 0.86 | 1-1/16 | 5/8 | 0.50 | 0.96 | 2.06 | 1 | 2.86 |
| 12-BUD | -1210-61 | 12BC12 | 3/4 | 0.86 | 1-3/16 | 3/4 | 0.63 | 0.96 | 2.31 | 1-1/8 | 3.11 |
| 14-BUD | -1410-61 | 14BC14 | 7/8 | 0.86 | 1-3/8 | 7/8 | 0.72 | 1.02 | 2.53 | 1-1/4 | 3.33 |
| 16-BUD | -1610-61 | 16BC16 | 1 | 1.04 | 1-5/8 | 1 | 0.88 | 1.23 | 2.81 | 1-1/2 | 3.77 |
At Jassem Tube Fittings, we are the leading supplier, manufacturer, and exporter of Bulkhead Union Elbow in Doha, Qatar. Our state-of-the-art manufacturing facilities, strategically located in the Qatar, empower us to provide high-quality solutions tailored to your specific requirements. With an extensive inventory of various premium materials, we are well-equipped to meet your needs efficiently. Our dedication to excellence and operational efficiency ensures we consistently maintain available stock, making us your trusted partner for reliable Union Cross fittings in various applications.
Jassem Tube Fittings is a leading supplier and stockist of premium Bulkhead Union Elbow in Doha, Qatar. Our products are widely utilized across various industries, recognized for their strength, durability, and reliable performance in connecting multiple pipe sections. We are committed to delivering exceptional service and ensuring high levels of customer satisfaction. Our advanced manufacturing techniques set us apart in the fittings industry, enabling us to consistently provide top-quality Union Cross fittings while effectively addressing the unique requirements of our customers.
Contact us to get a quick quote for your requirement.
Bulkhead Union Elbows find their place in systems where tubing needs to navigate through walls, panels, or equipment housings while changing direction. They’re commonly used in instrumentation panels, hydraulic and pneumatic systems, chemical processing units, and oil & gas installations. These fittings are perfect for connecting tubing in tight spaces and keeping piping layouts organized. They offer easy assembly, secure mounting, and leak-free performance, all of which contribute to enhanced system safety and efficiency. Their adaptability makes them a great choice for industrial, commercial, and processing applications alike.
